ZDP Series Double Disc Refiner

ZDP Series Double Disc Refiner is mainly used for beating and improving  the beating degree of pulp to satisfy the paper making demand.

Application & Features

  • ZDP Series Double Disc Refiner can be equipped with various tooth refiner plate.
  • Suitable various raw materials like wood pulp, chemical pulp, mechanical pulp and waste paper pulp.

Main Specification

Type Φ380 Φ450
Diameter of Disc(mm) 380 450
Production Capacity(t/d) 6-20 8-60
Concentration of InputPulp(%) 2-5 3.5
Pressure of Input Pulp(Mpa) 0.1-0.2 0.15-0.2
Motor Power(Kw) 37-55 75-90-110

Capacities vary depending on feed size, feed rate, operating conditions, desired product output, characteristics of feed material, and equipment configuration

Download complete technical literature [PDF]

Contact us or call +86 371 55129198 for more information.
